Starting from semi-processed materials, such as sugar and compounds, our machines can prepare any kind of drinks. We have a huge experience in developing customized syrup rooms according to the existing "on-factory" situation.
Beverage preparation & packaging
Efficiency in every drop:
our complete Beverage solutions.
Custom-made syrup rooms and highly precise fillers are part of our everyday business. We support small companies and international groups to design and install beverage preparation and beverage packaging solutions.
Benefits
Turn-key lines
Complete turn-key lines for beverage preparation and packaging, completely customized.
Integrated control system
Our HMI platforms Memento, Illuminate and FACTS can monitor machines and lines performance in a simple and intuitive way.
Hygienic design
Compliance with European and international guidelines.
Easy maintenance
Easy and cost-effective maintenance thanks to long-life wear components.
Unmatched quality
Technologies that guarantee an excellent product quality.
Filling precision
The swirl unit inside the filling valve is capable of operating perfect deflections on almost all containers on the market.
Select the line and discover its components
Processing
Packaging
Beverage preparation
-
Ingredients storage & Preparation
Ingredients storage & Preparation
- Storage tanks for different ingredients.
- Unloading station for fruit concentrate in drums or IBC.
- Big-Bag emptying unit with screw.
- Powders dissolving/dosing group.
-
Water storage
Water storage
Water storage tanks ensure precise management of water necessary for the preparation of beverages.
-
Blending
Blending
- Suitable for continuous or non-continuous solutions.
- Minimized product loss.
- High blending accuracy.
- Skid-mounted unit and low commissioning cost.
-
Deaeration and carbonation
Deaeration and carbonation
Premix: compact unit which includes carbonators and mixers that use the latest technology in the field of carbonation in conditions of saturation and blending in line of different beverages.
-
Pasteurization
Pasteurization
- Pasteurizer featuring different technologies (tubular/concentric, tube/scraped surface, heat exchanger systems, etc.…) for bulk drinks.
- Wide experience in many different products and applications.
- Respect of the organoleptic properties of the products.
-
CIP Unit
CIP Unit
Station equipped with 2 circuits and 4 tanks to wash with hot solutions and also to wash 2 different circuits at the same time.
Beverage packaging
-
Depalletizer CFT 201Depalletizer CFT 201
- High-level depalletizer for empty cans featuring 4 layers/min speed
- It is composed of full pallet lifting structure, pincers to hold the layer pads during the layer transfer, drawer-type belt conveyor with motors and manual guides adjustment
- It features 4000mm layer discharge table with motors and a motorized roller conveyor for full pallet inlet and one in the lifting area
-
Filler-Seamer monoblock Master C TechFiller-Seamer monoblock Master C Tech
Filler
- Designed for cans of carbonated and non-carbonated beverages
- Stainless steel construction ensures high hygiene standards
- The flow-meter technology guarantees a high precision in filling
- Simplified construction enables rapid maintenance
- Gas/product shutters and decompression units ensure reliability
- The machine is equipped with a servo motor system (electronic synchronization with seamer)
- Flexible software allows easy adaptation to various products
Seamer Series 3000/IB
- All main parts in the working area are made of stainless steel for more efficient cleaning as all materials are compatible with the most widely used cleaning
- Automatic greasing system for lubrication of the bottom part of the machine. The seaming head is watertight and oil-lubricated with an oil recirculation system. The seaming rolls too are lubricated with oil and they feature an oil recovery to prevent lubricant spillage in the area in contact with the container.
- Low maintenance costs, 24-hour non-stop operation, quick changeover
- Electronic operations control
-
Tunnel pasteurizerTunnel pasteurizer
- Products pass through the pasteurization tunnel on a conveyor belt, ensuring efficient and consistent heat treatment
- Utilizes hot water to raise the temperature of the product to a predetermined level
- Consists of multiple sections with controlled temperature and time settings to achieve pasteurization while minimizing product degradation
- Cooling phase to reduce thermal stress and maintain quality
- Equipped with automated controls and monitoring systems to ensure precise temperature and time control, enhancing efficiency and product safety
- Suitable for a variety of packaged beverages
- Designed to meet regulatory requirements for food safety and quality assurance
-
DryersDryers
- Cans dryers by means of air blowers to ensure packaging integrity
-
Dynamic accumulation systemDynamic accumulation system
- Track accumulator, ideal for delicate products, without pressure
- First in – First Out
- Accumulating in a continuous product flow but also eliminating larger gaps in the product flow.
- Preservation of bottle orientation between system infeed and outfeed
- Easy to inspect and easy to maintain
-
Shrink wrapping machineShrink wrapping machine
- Automatic wrapping machine able to form, load with product and wrap trays with shrink film
- The trays are picked-up from a high-capacity blank magazine and formed continuously around the product
- The machine is equipped with a shrink tunnel to achieve the final presentation
-
Palletizer CFT 601Palletizer CFT 601
- Single-infeed low-level automatic palletizer with 3 layers/min speed
- It is composed of a lifting structure, a pneumatic fall arrest system, a layer discharge basket with central opening and a motorized conveyor with motors and inverter, complete with pneumatic packages orientation device
-
Wrapping machineWrapping machine
- Automatic wrapping machine with rotary table to wrap pallets with stretch film
- The machine has an automatic clamp and cutting unit on a turntable designed to reach pallets perfectly, regardless of their position
- It includes an automatic pallet height reading photocell and rotation speed control for maximum cycle flexibility
Do you need more information?
Drink Types
Soft drinks
Starting from semi-processed materials, such as sugar and compounds, our machines can prepare any kind of drinks. We have a huge experience in developing customized syrup rooms according to the existing "on-factory" situation.
Other drinks
From spirits to ready-to-drink, via juices and plant-based drinks, our Beverage solutions include technologies for the preparation, filling, seaming and secondary packaging for a wide variety of products.
Beer
As CFT Group, we can supply turn-key beer production systems starting from the raw material intake up to the finished beer for brew sizes from 10 HL up to 500 HL, as well as the appropriate filling and packaging solutions for beer in bottles, cans and kegs.
Juices
Our diverse array of processing and packaging technologies includes the production of juices and smoothies. Engineered to mantain the ecceptional quality of fresh fruit, our solutions deliver an unparalleled taste and texture experience.
Drink Types | Juices
Our diverse array of processing and packaging technologies includes the production of juices and smoothies. Engineered to mantain the ecceptional quality of fresh fruit, our solutions deliver an unparalleled taste and texture experience.
View more videos of other Beverage types. Soft drinks, Other drinks, Beer, Water
Water
Our filling solutions for still and sparkling water in PET, glass bottles or cans boast important references all over the world.
